Chicago Pneumatic 7782-6
$597.00
Chicago Pneumatic 7782-6 is a product from Chicago Pneumatic for automotive tools. Documented configuration: Impact Wrench. Recorded product identifier: 6010136. ForgeBay SKU: FB-WR-6010136.
- Catalog SKU
- 6010136
- Product Type
- Air and Power Tools
- Brand
- Chicago Pneumatic
- Model
- 7782-6
Check brand, SKU, price, images, and product details.
- Diagnostics
- Hand tools
- Power tools
Product overview
Chicago Pneumatic Chicago Pneumatic 7782-6 is listed by ForgeBay Equipment for buyers comparing air and power tools, chicago pneumatic. ForgeBay Equipment is operated by EQUIPMENT4YOU, LLC.
Key specifications
- SKU
- FB-WR-6010136
- Brand
- Chicago Pneumatic
- Category
- Air and Power Tools, Chicago Pneumatic
- Availability
- In stock
- Price
- $597.00
- Catalog SKU
- 6010136
- Product Type
- Air and Power Tools
- Brand
- Chicago Pneumatic
- Model
- 7782-6
- MPN
- 6010136
- Application
- Automotive tools
What's included
Chicago Pneumatic 7782-6 includes the product shown in the listing title, image gallery, selected options, and any listed product documents. Optional accessories, installation supplies, and delivery appointment services are not included unless they are explicitly shown on the product page or order confirmation.
Compatibility / fitment
Confirm model fitment, capacity, measurements, power requirements, installation needs, generator wattage, voltage, phase, fuel type, transfer-switch compatibility, and accessory compatibility before ordering. Use the product SKU, documents, images, and category details when comparing fit.
Shipping Information
- Free shipping included.
- Orders are usually delivered within 7–14 business days after order confirmation.
- Some oversized equipment may require carrier appointment scheduling before delivery.
Warranty / support note
Warranty coverage and support details can vary by product and manufacturer. Contact ForgeBay Equipment with the SKU before ordering if you need warranty, parts, delivery, or installation-support information confirmed.
Returns note
Returns are handled according to the Refund Policy. Oversized, installed, or special-order products may require additional review before return approval.
Chicago Pneumatic 7782-6
Chicago Pneumatic 7782-6 is a product from Chicago Pneumatic for automotive tools. The documented configuration is Impact Wrench. Use ForgeBay SKU FB-WR-6010136 and recorded product identifier 6010136 to match this exact listing.
Key features
- 1" straight impact wrench with 6" extended anvil
- 1920 ft.lbs – 2600 Nm of maximum torque in reverse
- Pinless closed reinforced rocking dog impact mechanism
- Dual socket retention, hole and friction ring
- Ergonomic side handle
- Full teasing trigger
- Regulator with integrated forward/reverse with 3-position power settings in both directions
Verified specifications
| Product | Chicago Pneumatic 7782-6 |
|---|---|
| ForgeBay SKU | FB-WR-6010136 |
| Brand | Chicago Pneumatic |
| Model | 7782-6 |
| Recorded product identifier | 6010136 |
| Application | Automotive tools |
| Product weight | 32 lbs |
| Actual air consumption | 19.2 l/s / 40.7 cfm |
| Air inlet thread size | 1/2 " |
| Average air consumption | 4.8 l/s / 10 cfm |
| Blows per minute | 500 |
| Bolt size | M32 mm |
| Box dimensions | 670*245*130 mm / 26,35*9,6*5,11 " |
| Free speed | 5200 rpm |
| Length | 520 mm / 20.4 " |
| Maximum Torque (reverse) | 2600 Nm / 1920 ft.lbs |
| Min. hose size | 13 mm / 1/2 " |
| Net weight | 11.6 kg / 25.55 lb |
| Over carton | 670*245*130 mm / 26,35*9,6*5,11 " |
| Power/weight ratio | 257.4 Nm/kg / 86.5 ft.lb/lb |
| Sound Power | 111 db(A) |
| Sound pressure | 100 db(A) |
| Sound uncertainty | 3 db(A) |
| Square drive | 1 " |
| Vibration | 7.8 m/s² |
| Vibration ISO | Iso-28927-2 |
| Vibration uncertainty (K) | 1.8 m/s² |
| Working Torque Range (fwd) | 500 – 2000 Nm / 370 – 1475 ft.lbs |
Product reference: FB-WR-6010136.
| Catalog SKU | 6010136 |
|---|---|
| Product Type | Air and Power Tools |
| Brand | Chicago Pneumatic |
| Model | 7782-6 |
| MPN | 6010136 |
| Application | Automotive tools |
| Condition | New |
